HPOE-1200G - 12-Port Gigabit IEEE 802.3at PoE+ Managed Injector Hub

Акція до 10.12 -20% на купівлю даної модифікації від 50 шт. Знижка -20% в комплекті з товарами
HPOE-1200G -  12-Port Gigabit IEEE 802.3at PoE+ Managed Injector Hub
HPOE-1200G -  12-Port Gigabit IEEE 802.3at PoE+ Managed Injector Hub
HPOE-1200G -  12-Port Gigabit IEEE 802.3at PoE+ Managed Injector Hub
Hardware
Hardware Version 6
Interface “Data” Input Ports:12 x RJ45
“Data + Power” Output Ports:12 x RJ45
Management Port:1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX
Data Rate 10/100/1000Mbps
Power Requirements 100-240V AC, 50/60 Hz, 8A
Power Consumption 382 watts/1303 BTU
Ventilation Smart Fan x 2
Dimensions (W x D x H) 440 x 300 x 44mm
Weight 3.9kg
Reset Button < 5 sec: System reboot
> 5 sec: Factory default
LED System: SYS PWR x 1 (Green)
    PoE Failure x 1 (Red)
    Fan 1 Failure x 1 (Red)
    Fan 2 Failure x 1 (Red)
    Per PoE Port: PoE-in-use x 1 (Amber)
Management port x 1 : LNK/ACT (Green)
Network Cable 10BASE-T: 4-pair UTP Cat5 up to 100m (328ft)
100BASE-TX: 4-pair UTP Cat5 up to 100m (328ft)
1000BASE-T: 4-pair UTP Cat5e/6 up to 100m (328ft)
EIA/TIA- 568 100-ohm STP (100m)
Power over Ethernet
PoE Power Supply Type Mid-span
PoE Power Output Per port DC 54V 30.8/15.4 watts
Power Pin Assignment 4/5(+), 7/8(-)
PoE Power Budget 360 watts
Number of 802.3af PDs (Class 0, 1, 2, 3) can be powered 12
Number of 802.3at PDs (Class 1, 2, 3) can be powered 12
Number of 802.3at PDs (Class 0, 4) can be powered 12
Security
Firewall SPI Firewall Protection
Filtering MAC Filtering
Certificates System CA Certificate for HTTPS
Management
Management Interface Web, PLANET Smart Discovery Lite
Secure Management Interface TLSv1.2, TLSv1.3
Secure Management Interface TLSv1.2, TLSv1.3
PoE Management Power limit by consumption and classification
PoE function enable/disable
Per port PoE function enable/disable
Per port PoE power schedule
Power feeding priority
PD alive check
PD classification detection
Current per port usage and status
Total power consumption
Management Feature IPv4 and IPv6 dual stack management
Web interface for remote management
PLANET DDNS and Easy DDNS
Supports Network Time Protocol (NTP)
System Maintenance
   Firmware upload via HTTP
   Configuration upload/download via HTTP
   Reboot button for system reboot
   Reset button for system reset to factory default
PLANET Smart Discovery utility
PLANET NMS system and CloudViewer for deployment management
SNMP v1, v2c and v3 for system status monitoring
SNMP trap for alarm notification of events
System event log/remote syslog
Scheduled System Power Rebooting
Network Diagnostic
  ICMPv6/ICMPv4 Remote Ping
  Trace Route
Standards Conformance
Regulatory Compliance FCC Part 15 Class A, CE
Standards Compliance IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3at Power over Ethernet Plus
IEEE 802.3af Power over Ethernet
RFC 768: UDP
RFC 791: IP
RFC 2068 HTTP
RFC 1157: SNMP v1
RFC 1902: SNMP v2c
RFC 2273: SNMPv3
RFC 5424: Syslog
Environments
Operating Temperature: 0 ~ 50 degrees C
Relative Humidity: 5 ~ 90% (non-condensing)
Storage Temperature: -10 ~ 70 degrees C
Relative Humidity: 5 ~ 90% (non-condensing)
