Коммутаторы, маршрутизаторы
от 23638 грн
L3 2-Port 100/1000T + 2-Port 100/1G SFP + 4-Port 100/1G/2.5G SFP + 2-Port 10G SFP+ Managed Metro Ethernet Switch (AC+DC Power Redundant, 2xDI, 2xDO, Hardware Layer 3 RIPv1/v2, OSPFv2/v3 dynamic routing, supports ERPS Ring, CloudViewer app, MQTT, Cybersecurity features)
L3 2-Port 100/1000T + 2-Port 100/1G SFP + 4-Port 100/1G/2.5G SFP + 2-Port 10G SFP+ Managed Metro Ethernet Switch (AC+DC Power Redundant, 2xDI, 2xDO, Hardware Layer 3 RIPv1/v2, OSPFv2/v3 dynamic routing, supports ERPS Ring, CloudViewer app, MQTT, Cybersecurity features)
Layer 3 12-Port 10GBASE-X SFP+ + 4-Port 10GBASE-T Managed Ethernet Switch with 48V DC Redundant Power (Hardware Layer 3 RIPv1/v2, OSPFv2/v3 dynamic routing, supports ERPS Ring, CloudViewer app, MQTT, Cybersecurity features, supports 1000X, 2.5G SFP and 10G SFP+)
Layer 3 12-Port 10GBASE-X SFP+ + 4-Port 10GBASE-T Managed Ethernet Switch with 48V DC Redundant Power (Hardware Layer 3 RIPv1/v2, OSPFv2/v3 dynamic routing, supports ERPS Ring, CloudViewer app, MQTT, Cybersecurity features, supports 1000X, 2.5G SFP and 10G SFP+)
от 52744 грн
L3 46-Port 100/1000BASE-X SFP + 2-Port Gigabit TP/SFP combo + 4-Port 10G SFP+ Managed Switch W/ 48V Redundant Power (AC+DC Power Redundant, Cybersecurity features, Hardware Layer3 OSPFv2 and IPv4/IPv6 Static Routing)
L3 46-Port 100/1000BASE-X SFP + 2-Port Gigabit TP/SFP combo + 4-Port 10G SFP+ Managed Switch W/ 48V Redundant Power (AC+DC Power Redundant, Cybersecurity features, Hardware Layer3 OSPFv2 and IPv4/IPv6 Static Routing)
13" 6-Port 100/1G SFP + 2-Port 1G/2.5G SFP + 2-Port 10/100/1000T L2/L4 Managed Metro Ethernet Switch (AC+2 DC, DIDO, ERPS Ring, CloudViewer app, MQTT and Cybersecurity features, IPv4/IPv6 Static Routing, supports 100FX, 1000X and 2.5G SFP)
13" 6-Port 100/1G SFP + 2-Port 1G/2.5G SFP + 2-Port 10/100/1000T L2/L4 Managed Metro Ethernet Switch (AC+2 DC, DIDO, ERPS Ring, CloudViewer app, MQTT and Cybersecurity features, IPv4/IPv6 Static Routing, supports 100FX, 1000X and 2.5G SFP)
16-Port 100/1000Base-X SFP + 8-Port 10/100/1000Base-T L2/L4 Managed Metro Ethernet Switch (AC+2 DC, DIDO)
16-Port 100/1000Base-X SFP + 8-Port 10/100/1000Base-T L2/L4 Managed Metro Ethernet Switch (AC+2 DC, DIDO)
от 37573 грн
L3 14*100/1G SFP with 4 shared 10/100/1000T + 10*1G/2.5G SFP + 4*10G SFP+ Managed Metro Ethernet Switch (AC+DC Power Redundant, 2xDI, 2xDO, Cybersecurity features, Hardware Layer3 OSPFv2 and IPv4/IPv6 Static Routing, supports CloudViewer app and MQTT),EN61000-6-2/-4 Heavy Industrial EMC certified
L3 14*100/1G SFP with 4 shared 10/100/1000T + 10*1G/2.5G SFP + 4*10G SFP+ Managed Metro Ethernet Switch (AC+DC Power Redundant, 2xDI, 2xDO, Cybersecurity features, Hardware Layer3 OSPFv2 and IPv4/IPv6 Static Routing, supports CloudViewer app and MQTT),EN61000-6-2/-4 Heavy Industrial EMC certified
IPv4/IPv6 Managed 8-Port 10/100/1000Mbps + 2-Port 100/1000X SFP Gigabit Desktop Ethernet Switch (POE PD, External PWR, SNMPv3, 802.1Q VLAN, IGMP Snooping, TLS, SSH, ACL, supports ERPS Ring, CloudViewer app, MQTT and Cybersecurity feature)
IPv4/IPv6 Managed 8-Port 10/100/1000Mbps + 2-Port 100/1000X SFP Gigabit Desktop Ethernet Switch (POE PD, External PWR, SNMPv3, 802.1Q VLAN, IGMP Snooping, TLS, SSH, ACL, supports ERPS Ring, CloudViewer app, MQTT and Cybersecurity feature)
| Hardware Specifications | |
|---|---|
| Copper Ports | 8 x 10/100/1000BASE-T RJ45 Auto-MDI/MDI-X ports |
| SFP Ports | 2 x 100/1000BASE-X SFP interfaces Supports 100/1000Mbps dual mode and DDM |
| Console | 1 x RS-232-to-RJ45 serial port (115200, 8, N, 1) |
| Reset Button | < 5 sec: System reboot > 5 sec: Factory default |
| Dimensions (W x D x H) | 280 x 180 x 44 mm, 1U height |
| Weight | 1315g |
| Enclosure | Metal |
| Power Requirements | AC 100~240V, 50/60Hz, 2.5A, auto-sensing |
| Power Consumption/ Dissipation | 6.8 watts/ 23.2 BTU |
| ESD Protection | Contact Discharge 6KV DC Air Discharge 8KV DC |
| Fan | Fanless design |
| LED | System: PWR x1 (Green) SYS x1 (Green) Per PoE Port (Port 1 to Port 8): LNK/ACT x1 (Green) Per Gigabit SFP Port (Port 9 to Port 10): 100/1000 LNK/ACT x1 (Green) |
| Switching Specifications | |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 20Gbps/non-blocking |
| Switch Throughput@64Bytes | 14.88Mpps |
| Address Table | 8K entries |
| Shared Data Buffer | 4.1 megabits |
| Flow Control | IEEE 802.3x pause frame for full duplex Back pressure for half duplex |
| Jumbo Frame | 10K bytes |
| Layer 2 Functions | |
| Port Mirroring | TX/RX/both Many-to-1 monitor Up to 4 sessions |
| VLAN | IEEE 802.1Q tagged VLAN IEEE 802.1ad Q-in-Q tunneling Voice VLAN Protocol VLAN Private VLAN (Protected port) GVRP Up to 256 VLAN groups, out of 4094 VLAN IDs |
| Link Aggregation | IEEE 802.3ad LACP/Static Trunk Supports1 trunk group with 2 ports per trunk |
| Spanning Tree Protocol | IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) STP BPDU Guard, BPDU Filtering and BPDU Forwarding |
| IGMP Snooping | IPv4 IGMP (v2/v3) Snooping IPv4 IGMP Querier Up to 256 multicast groups |
| MLD Snooping | IPv6 MLD (v1/v2) Snooping Up to 256 multicast groups |
| QoS | 8 mapping ID to 8 level priority queues - Port number - 802.1p priority - 802.1Q VLAN tag - DSCP field in IP packet Traffic classification based, strict priority and WRR |
| Ring | Supports ERPS, and complies with ITU-T G.8032 |
| Security Functions | |
| Access Control List | IPv4/IPv6 IP-based ACL MAC-based ACL |
| Security | P-MAC port binding MAC filter Static MAC address DHCP Snooping and DHCP Option82 DoS attack prevention ARP inspection IP source guard |
| AAA | Built-in RADIUS client to co-operate with RADIUS server |
| Network Access Control | IEEE 802.1X – Port-based authentication RADIUS/TACACS+ user access authentication |
| Management Functions | |
| Basic Management Interfaces | RS232 console Web browser Telnet SNMP v1, v2c |
| Secure Management Interfaces | SSHv2, TLS v1.2, SNMP v3 |
| System Management | Firmware upgrade by HTTP/TFTP protocol through Ethernet network LLDP protocol SNTP PLANET Smart Discovery Utility PLANET NMS System |
| Event Management | Remote/Local Syslog System log |
| SNMP MIBs | RFC 1213 MIB-II RFC 1215 Generic Traps RFC 1493 Bridge MIB RFC 2674 Bridge MIB Extensions RFC 2737 Entity MIB (Version 2) RFC 2819 RMON (1, 2, 3, 9) RFC 2863 Interface Group MIB RFC 3635 Ethernet-like MIB |
| Standards Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX/100BASE-FX IEEE 802.3z Gigabit SX/LX IEEE 802.3ab Gigabit 1000T IEEE 802.3x flow control and back pressure IEEE 802.3ad port trunk with LACP IEEE 802.1D Spanning Tree protocol IEEE 802.1w Rapid Spanning Tree protocol IEEE 802.1s Multiple Spanning Tree protocol IEEE 802.1p Class of Service IEEE 802.1Q VLAN tagging IEEE 802.1x Port Authentication Network Control IEEE 802.1ab LLDP IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus RFC 768 UDP RFC 793 TFTP RFC 791 IP RFC 792 ICMP RFC 2068 HTTP RFC 1112 IGMP version 1 RFC 2236 IGMP version 2 RFC 3376 IGMP version 3 RFC 2710 MLD version 1 RFC 3810 MLD version 2 ITU G.8032 ERPS Ring |
| Environment | |
| Operating | Temperature: 0 ~ 50 degrees C Relative Humidity: 5 ~ 95% (non-condensing) |
| Storage | Temperature: -20 ~ 70 degrees C Relative Humidity: 5 ~ 95% (non-condensing) |
| Hardware Specifications | |
|---|---|
| Copper Ports | 8 x 10/100/1000BASE-T RJ45 Auto-MDI/MDI-X ports |
| SFP Ports | 2 x 100/1000BASE-X SFP interfaces Supports 100/1000Mbps dual mode and DDM |
| Console | 1 x RS-232-to-RJ45 serial port (115200, 8, N, 1) |
| Reset Button | < 5 sec: System reboot > 5 sec: Factory default |
| Dimensions (W x D x H) | 280 x 180 x 44 mm, 1U height |
| Weight | 1315g |
| Enclosure | Metal |
| Power Requirements | AC 100~240V, 50/60Hz, 2.5A, auto-sensing |
| Power Consumption/ Dissipation | 6.8 watts/ 23.2 BTU |
| ESD Protection | Contact Discharge 6KV DC Air Discharge 8KV DC |
| Fan | Fanless design |
| LED | System: PWR x1 (Green) SYS x1 (Green) Per PoE Port (Port 1 to Port 8): LNK/ACT x1 (Green) Per Gigabit SFP Port (Port 9 to Port 10): 100/1000 LNK/ACT x1 (Green) |
| Switching Specifications | |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 20Gbps/non-blocking |
| Switch Throughput@64Bytes | 14.88Mpps |
| Address Table | 8K entries |
| Shared Data Buffer | 4.1 megabits |
| Flow Control | IEEE 802.3x pause frame for full duplex Back pressure for half duplex |
| Jumbo Frame | 10K bytes |
| Layer 2 Functions | |
| Port Mirroring | TX/RX/both Many-to-1 monitor Up to 4 sessions |
| VLAN | IEEE 802.1Q tagged VLAN IEEE 802.1ad Q-in-Q tunneling Voice VLAN Protocol VLAN Private VLAN (Protected port) GVRP Up to 256 VLAN groups, out of 4094 VLAN IDs |
| Link Aggregation | IEEE 802.3ad LACP/Static Trunk Supports1 trunk group with 2 ports per trunk |
| Spanning Tree Protocol | IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) STP BPDU Guard, BPDU Filtering and BPDU Forwarding |
| IGMP Snooping | IPv4 IGMP (v2/v3) Snooping IPv4 IGMP Querier Up to 256 multicast groups |
| MLD Snooping | IPv6 MLD (v1/v2) Snooping Up to 256 multicast groups |
| QoS | 8 mapping ID to 8 level priority queues - Port number - 802.1p priority - 802.1Q VLAN tag - DSCP field in IP packet Traffic classification based, strict priority and WRR |
| Ring | Supports ERPS, and complies with ITU-T G.8032 |
| Security Functions | |
| Access Control List | IPv4/IPv6 IP-based ACL MAC-based ACL |
| Security | P-MAC port binding MAC filter Static MAC address DHCP Snooping and DHCP Option82 DoS attack prevention ARP inspection IP source guard |
| AAA | Built-in RADIUS client to co-operate with RADIUS server |
| Network Access Control | IEEE 802.1X – Port-based authentication RADIUS/TACACS+ user access authentication |
| Management Functions | |
| Basic Management Interfaces | RS232 console Web browser Telnet SNMP v1, v2c |
| Secure Management Interfaces | SSHv2, TLS v1.2, SNMP v3 |
| System Management | Firmware upgrade by HTTP/TFTP protocol through Ethernet network LLDP protocol SNTP PLANET Smart Discovery Utility PLANET NMS System |
| Event Management | Remote/Local Syslog System log |
| SNMP MIBs | RFC 1213 MIB-II RFC 1215 Generic Traps RFC 1493 Bridge MIB RFC 2674 Bridge MIB Extensions RFC 2737 Entity MIB (Version 2) RFC 2819 RMON (1, 2, 3, 9) RFC 2863 Interface Group MIB RFC 3635 Ethernet-like MIB |
| Standards Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX/100BASE-FX IEEE 802.3z Gigabit SX/LX IEEE 802.3ab Gigabit 1000T IEEE 802.3x flow control and back pressure IEEE 802.3ad port trunk with LACP IEEE 802.1D Spanning Tree protocol IEEE 802.1w Rapid Spanning Tree protocol IEEE 802.1s Multiple Spanning Tree protocol IEEE 802.1p Class of Service IEEE 802.1Q VLAN tagging IEEE 802.1x Port Authentication Network Control IEEE 802.1ab LLDP IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus RFC 768 UDP RFC 793 TFTP RFC 791 IP RFC 792 ICMP RFC 2068 HTTP RFC 1112 IGMP version 1 RFC 2236 IGMP version 2 RFC 3376 IGMP version 3 RFC 2710 MLD version 1 RFC 3810 MLD version 2 ITU G.8032 ERPS Ring |
| Environment | |
| Operating | Temperature: 0 ~ 50 degrees C Relative Humidity: 5 ~ 95% (non-condensing) |
| Storage | Temperature: -20 ~ 70 degrees C Relative Humidity: 5 ~ 95% (non-condensing) |
IPv4/IPv6, 16-Port 10/100/1000Base-T + 2-Port 100/1000MBPS SFP L2/L4 SNMP Manageable Gigabit Ethernet Switch(supports ERPS Ring, CloudViewer app, MQTT and Cybersecurity feature)
IPv4/IPv6, 16-Port 10/100/1000Base-T + 2-Port 100/1000MBPS SFP L2/L4 SNMP Manageable Gigabit Ethernet Switch(supports ERPS Ring, CloudViewer app, MQTT and Cybersecurity feature)
Популярные товары
от 1638 грн
SFP+ трансивер CWDM DFB 10 Гбит/с предназначен для передачи и приема оптических данных по одномодовому оптическому волокну на длину линии связи 20 км. Электрический интерфейс модуля CWDM SFP+ LR соответствует электрическим спецификациям SFI.
Широкий выбор коммутаторов и маршрутизаторов от ведущих мировых производителей, идеально подходящих для создания надежных интернет-сетей для бизнеса. Управляемые и неуправляемые, Fast Ethernet и Gigabit Ethernet коммутаторы уровня 2 и уровня 3 с различным количеством Ethernet портов и SFP или SFP + слотов и поддержкой PoE. Наши коммутаторы и маршрутизаторы отличаются высоким качеством, надежностью и удобством в монтаже. Выбирайте по техническим характеристикам и цене, используя удобные фильтры. Каждый товар сопровождается подробными техническими спецификациями и техническими паспортами описанием. Выбирайте лучшее сетевое оборудование у нас! Наши сетевые решения позволяют эффективно управлять вашей сетью, обеспечивая стабильную связь и высокую производительность. Независимо от того, нужно ли вам сетевое оборудование для малого офиса или крупного предприятия, у нас есть решения, которые соответствуют вашим потребностям.
