UPOE-2400G - 24-Port Gigabit 802.3bt PoE++ Managed Injector Hub (800 watts)

Акція до 10.12 -20% на купівлю даної модифікації від 50 шт. Знижка -20% в комплекті з товарами
UPOE-2400G - 24-Port Gigabit 802.3bt PoE++ Managed Injector Hub (800 watts)
UPOE-2400G - 24-Port Gigabit 802.3bt PoE++ Managed Injector Hub (800 watts)
UPOE-2400G - 24-Port Gigabit 802.3bt PoE++ Managed Injector Hub (800 watts)
Hardware
Interface Management Port:1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX
“Data”Input Ports:24 x RJ45
“Data + Power” Output Ports:24 x RJ45
Data Rate 10/100/1000Mbps
Power Requirements 100-240V AC, 50/60 Hz, 15A
Power Consumption 968 watts/3302 BTU
Ventilation Smart Fan x 3
Dimensions (W x D x H) 440 x 300 x 44.5mm
Weight 5.4kg
Reset Button < 5 sec: System reboot
> 5 sec: Factory default
LED System: SYS PWR x 1 (Green)
PoE Failure x 1 (Red)
Fan Failure x 2 (Red)
Management port x 1: LNK/ACT (Green),
Per PoE Port: 802.3bt/UPoE PoE-in-use x 1 (Green)
802.3at/af PoE-in-use x1 (Amber)
Network Cable 10BASE-T: 4-pair UTP Cat5 up to 100m (328ft)
100BASE-TX: 4-pair UTP Cat5 up to 100m (328ft)
1000BASE-T: 4-pair UTP Cat5e/6 up to 100m (328ft)
EIA/TIA- 568 100-ohm STP (100m)
Power over Ethernet
PoE Standard 802.3bt PoE++ PSE
Backward compatible with IEEE 802.3at PoE PSE
PoE Power Supply Mode 802.3bt
End-span
Mid-span
PoE Power Output Per port 54V DC
 802.3bt mode: maximum 95 watts
 End-span mode: maximum 36 watts
 Mid-span mode: maximum 36 watts
Power Pin Assignment 802.3bt: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
End-span: 1/2(-), 3/6(+)
Mid-span: 4/5(+), 7/8(-)
PoE PD Type Standard
Legacy
Force
PoE Power Budget 800 watts
Number of 95W 802.3bt Type-4 PDs 8
Number of 60W 802.3bt Type-3 PDs 13
Number of 802.3at PDs 22
PoE Management Power limit by consumption and classification
PoE function enable/disable
Per port PoE function enable/disable
Per port PoE power schedule
Power feeding priority
PD alive check
PD classification detection
Current per port usage and status
Total power consumption
Security
Firewall SPI Firewall Protection
Filtering MAC Filtering
Certificates System CA Certificate for HTTPS
Management Functions
Management Interface HTTP/HTTPs Web user interface
Secure Management Interface TLSv1.2, TLSv1.3
Management Feature IPv4 and IPv6 dual stack management
Web interface for remote management
PLANET DDNS and Easy DDNS
Supports Network Time Protocol (NTP)
System Maintenance
 Firmware upload via HTTP
 Configuration upload/download via HTTP
 Reboot button for system reboot
 Reset button for system reset to factory default
PLANET Smart Discovery utility
PLANET NMS system and CloudViewer for deployment management
Scheduled System Power RebootingNetwork Diagnostic
 ICMPv6/ICMPv4 Remote Ping
 Trace Route
SNMP Management SNMP v1, v2c and v3 for system status monitoring
SNMP trap for alarm notification of events
Event Management Local system event log
Remote syslog
Standards Conformance
Regulatory Compliance FCC Part 15 Class A, CE
Standards Compliance IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
IEEE 802.3bt Power over Ethernet Plus Plus
RFC 768: UDP
RFC 791: IP
RFC 2068 HTTP
RFC 1157: SNMP v1
RFC 1902: SNMP v2c
RFC 2273: SNMPv3
RFC 5424: Syslog
Environments
Operating Temperature: 0 ~ 50 degrees C
Relative Humidity: 5 ~ 90% (non-condensing)
Storage Temperature: -10 ~ 70 degrees C
Relative Humidity: 5 ~ 90% (non-condensing)
