Сетевое оборудование с PoE
Стекируемый управляемый коммутатор 3 уровня 48 портов 10/100/1000T 802.3at PoE + 6 портов 10G SFP+ (AC 370W, AC+DC 740W PoE бюджет, аппаратное стекирование до 8 устройств, аппаратная маршрутизация 3 уровня IPv4/IPv6 и VRRP, поддержка ERPS Ring)
Стекируемый управляемый коммутатор 3 уровня 48 портов 10/100/1000T 802.3at PoE + 6 портов 10G SFP+ (AC 370W, AC+DC 740W PoE бюджет, аппаратное стекирование до 8 устройств, аппаратная маршрутизация 3 уровня IPv4/IPv6 и VRRP, поддержка ERPS Ring)
8-портовый 10/100TX 802.3at PoE + 2-портовый гигабитный TP/SFP комбинированный настольный коммутатор с интеллектуальным цветным ЖК-дисплеем (бюджет PoE 120 Вт, стандартный режим/VLAN/Extend, бюджет PoE, контроль полосы пропускания, настройка проверки PD в живом состоянии через ЖК-дисплей)
8-портовый 10/100TX 802.3at PoE + 2-портовый гигабитный TP/SFP комбинированный настольный коммутатор с интеллектуальным цветным ЖК-дисплеем (бюджет PoE 120 Вт, стандартный режим/VLAN/Extend, бюджет PoE, контроль полосы пропускания, настройка проверки PD в живом состоянии через ЖК-дисплей)
16-портовый 10/100TX 802.3at PoE + 2-портовый 10/100/1000T + 2-портовый 1000X SFP Ethernet-коммутатор с интеллектуальным цветным ЖК-дисплеем (бюджет PoE 300 Вт, стандартный режим/VLAN/Extend, бюджет PoE, контроль полосы пропускания, настройка проверки живого PD через ЖК-дисплей)
16-портовый 10/100TX 802.3at PoE + 2-портовый 10/100/1000T + 2-портовый 1000X SFP Ethernet-коммутатор с интеллектуальным цветным ЖК-дисплеем (бюджет PoE 300 Вт, стандартный режим/VLAN/Extend, бюджет PoE, контроль полосы пропускания, настройка проверки живого PD через ЖК-дисплей)
24-Port 10/100TX 802.3at PoE + 2-Port 10/100/1000T + 2-Port 1000X SFP Ethernet Switch with smart color LCD (300W PoE Budget, Standard/VLAN/Extend mode, PoE Budget, bandwidth control, PD alive check setup over LCD )
24-Port 10/100TX 802.3at PoE + 2-Port 10/100/1000T + 2-Port 1000X SFP Ethernet Switch with smart color LCD (300W PoE Budget, Standard/VLAN/Extend mode, PoE Budget, bandwidth control, PD alive check setup over LCD )
| Hardware Specifications | |
|---|---|
| 802.3af/802.3at PoE Injector Port | 8 |
| 10/100/1000BASE-T MDI/MDIX Ports | 8 |
| 10/100/1000BASE-T MDI/MDIX Ports | 2 |
| 1000BASE-X SFP/mini-GBIC Slots | 2 |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 24Gbps/non-blocking |
| Switch Throughput@64 bytes | 18Mpps@64 bytes |
| MAC Address Table | 8K entries |
| Maximum Frame Size | 9216 bytes |
| Flow Control | IEEE 802.3x pause frame for full duplex; back pressure for half duplex |
| LED | System: Power (Green) PoE interfaces: PoE-in-Use (Orange) 10/100/1000BASE-T RJ45 Interfaces: 10/100Mbps LNK/ACT (Red) 1000Mbps LNK/ACT (Green) 1000BASE-X SFP Interfaces: LNK/ACT (Green) |
| LCD Monitor (W x D) | 40.6mm x 30.5mm, 2-inch |
| Buttons | Menu, Enter, Back, Up and Down |
| Dimensions (W x D x H) | 180 x 280 x 44mm (1U height) |
| Enclosure | Metal |
| Weight | 1671g |
| Power Requirements | 100~240V AC, 50/60Hz, 2.5A max. |
| Power Consumption/Dissipation | Max. 130 watts/446 BTU |
| Thermal Fan | 1 |
| ESD Protection | Contact discharge of ±6KV DC Air discharge of ±8KV DC |
| Surge Protection | ±6KV |
| Power over Ethernet | |
| PoE Standard | IEEE 802.3af Power over Ethernet/PSE IEEE 802.3at Power over Ethernet Plus/PSE |
| PoE Power Supply Type | End-span |
| PoE Power Output | Per port 54V DC, 300mA. max. 15.4 watts (IEEE 802.3af) Per port 54V DC, 600mA. max. 30 watts (IEEE 802.3at) |
| Power Pin Assignment | 1/2 (+), 3/6 (-) |
| PoE Power Budget | 120 watts |
| Max. Number of Class 2 PDs | 8 |
| Max. Number of Class 3 PDs | 8 |
| Max. Number of Class 4 PDs | 4 |
| Standards Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab Gigabit 1000BASE-T IEEE 802.3z Gigabit SX/LX IEEE 802.3x Flow control and back pressure IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus IEEE 802.3az Energy Efficient Ethernet (EEE) |
| Environment | |
| Operating | Temperature: -10 ~ 60 degrees C Relative Humidity: 10 ~ 90% (non-condensing) * Temperature<40 degrees C; Humidity<90% Temperature>40 degrees C; Humidity<50% |
| Storage | Temperature: -10 ~ 70 degrees C Relative Humidity: 5 ~ 90% (non-condensing) |
| Hardware Specifications | |
|---|---|
| 802.3af/802.3at PoE Injector Port | 8 |
| 10/100/1000BASE-T MDI/MDIX Ports | 8 |
| 10/100/1000BASE-T MDI/MDIX Ports | 2 |
| 1000BASE-X SFP/mini-GBIC Slots | 2 |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 24Gbps/non-blocking |
| Switch Throughput@64 bytes | 18Mpps@64 bytes |
| MAC Address Table | 8K entries |
| Maximum Frame Size | 9216 bytes |
| Flow Control | IEEE 802.3x pause frame for full duplex; back pressure for half duplex |
| LED | System: Power (Green) PoE interfaces: PoE-in-Use (Orange) 10/100/1000BASE-T RJ45 Interfaces: 10/100Mbps LNK/ACT (Red) 1000Mbps LNK/ACT (Green) 1000BASE-X SFP Interfaces: LNK/ACT (Green) |
| LCD Monitor (W x D) | 40.6mm x 30.5mm, 2-inch |
| Buttons | Menu, Enter, Back, Up and Down |
| Dimensions (W x D x H) | 180 x 280 x 44mm (1U height) |
| Enclosure | Metal |
| Weight | 1671g |
| Power Requirements | 100~240V AC, 50/60Hz, 2.5A max. |
| Power Consumption/Dissipation | Max. 130 watts/446 BTU |
| Thermal Fan | 1 |
| ESD Protection | Contact discharge of ±6KV DC Air discharge of ±8KV DC |
| Surge Protection | ±6KV |
| Power over Ethernet | |
| PoE Standard | IEEE 802.3af Power over Ethernet/PSE IEEE 802.3at Power over Ethernet Plus/PSE |
| PoE Power Supply Type | End-span |
| PoE Power Output | Per port 54V DC, 300mA. max. 15.4 watts (IEEE 802.3af) Per port 54V DC, 600mA. max. 30 watts (IEEE 802.3at) |
| Power Pin Assignment | 1/2 (+), 3/6 (-) |
| PoE Power Budget | 120 watts |
| Max. Number of Class 2 PDs | 8 |
| Max. Number of Class 3 PDs | 8 |
| Max. Number of Class 4 PDs | 4 |
| Standards Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab Gigabit 1000BASE-T IEEE 802.3z Gigabit SX/LX IEEE 802.3x Flow control and back pressure IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus IEEE 802.3az Energy Efficient Ethernet (EEE) |
| Environment | |
| Operating | Temperature: -10 ~ 60 degrees C Relative Humidity: 10 ~ 90% (non-condensing) * Temperature<40 degrees C; Humidity<90% Temperature>40 degrees C; Humidity<50% |
| Storage | Temperature: -10 ~ 70 degrees C Relative Humidity: 5 ~ 90% (non-condensing) |
16-Port 10/100/1000T 802.3at PoE + 2-Port 1000X SFP Gigabit Switch with smart color LCD (300W PoE Budget, Standard/VLAN/Extend mode, PoE budget, bandwidth control, PD alive check setup over LCD)
16-Port 10/100/1000T 802.3at PoE + 2-Port 1000X SFP Gigabit Switch with smart color LCD (300W PoE Budget, Standard/VLAN/Extend mode, PoE budget, bandwidth control, PD alive check setup over LCD)
24-Port 10/100/1000T 802.3at PoE + 2-Port 1000SX SFP Gigabit Switch with smart color LCD (300W PoE Budget, Standard/VLAN/Extend mode, PoE Budget, bandwidth control, PD alive check setup over LCD )
24-Port 10/100/1000T 802.3at PoE + 2-Port 1000SX SFP Gigabit Switch with smart color LCD (300W PoE Budget, Standard/VLAN/Extend mode, PoE Budget, bandwidth control, PD alive check setup over LCD )
от 27984 грн
L3 8-Port 10/100/1000T 95W 802.3bt PoE + 2-Port 10/100/1000T + 2-Port 10G SFP+ Managed Switch (240W PoE Budget, 200m Extend mode, ERPS Ring, ONVIF, MQTT, Cybersecurity features, Hardware Layer3 OSPFv2 and IPv4/IPv6 Static Routing, supports1G,2.5G and 10G SFP+)
L3 8-Port 10/100/1000T 95W 802.3bt PoE + 2-Port 10/100/1000T + 2-Port 10G SFP+ Managed Switch (240W PoE Budget, 200m Extend mode, ERPS Ring, ONVIF, MQTT, Cybersecurity features, Hardware Layer3 OSPFv2 and IPv4/IPv6 Static Routing, supports1G,2.5G and 10G SFP+)
8-Port 10/100/1000T 802.3at PoE + 2-Port 10/100/1000T Desktop Switch (120W PoE Budget, Standard/VLAN/Extend mode, supports PD alive check, 10-inch and rack-mountable)
8-Port 10/100/1000T 802.3at PoE + 2-Port 10/100/1000T Desktop Switch (120W PoE Budget, Standard/VLAN/Extend mode, supports PD alive check, 10-inch and rack-mountable)
Layer 3, 8-Port 2.5GBASE-T 802.3at PoE + 2-Port 10GBASE-X SFP+ Managed Ethernet Switch(120W PoE budget, hardware-based Layer 3 RIPv1/v2, OSPFv2 dynamic routing, supports ERPS Ring, PoE PD alive check and schedule management)
Layer 3, 8-Port 2.5GBASE-T 802.3at PoE + 2-Port 10GBASE-X SFP+ Managed Ethernet Switch(120W PoE budget, hardware-based Layer 3 RIPv1/v2, OSPFv2 dynamic routing, supports ERPS Ring, PoE PD alive check and schedule management)
Layer 3 8-Port 10/100/1000T 90W 802.3bt PoE + 16-Port 10/100/1000T 802.3at PoE + 4-Port 10G SFP+ Managed Ethernet Switch (475 Watts PoE budget, hardware-based Layer 3 RIPv1/v2, OSPFv2 dynamic routing, supports ERPS Ring, PoE PD alive check and schedule management,)
Layer 3 8-Port 10/100/1000T 90W 802.3bt PoE + 16-Port 10/100/1000T 802.3at PoE + 4-Port 10G SFP+ Managed Ethernet Switch (475 Watts PoE budget, hardware-based Layer 3 RIPv1/v2, OSPFv2 dynamic routing, supports ERPS Ring, PoE PD alive check and schedule management,)
Layer 3 24-Port 10/100/1000T 802.3at PoE + 4-Port 10G SFP+ Managed Ethernet Switch with Smart LCD Screen(370 Watts PoE budget, hardware-based Layer 3 RIPv1/v2, OSPFv2 dynamic routing, supports ERPS Ring, PoE PD alive check and schedule management; supports Standard/VLAN/Extend mode, PoE Budget, bandwidth control setup over LCD)
Layer 3 24-Port 10/100/1000T 802.3at PoE + 4-Port 10G SFP+ Managed Ethernet Switch with Smart LCD Screen(370 Watts PoE budget, hardware-based Layer 3 RIPv1/v2, OSPFv2 dynamic routing, supports ERPS Ring, PoE PD alive check and schedule management; supports Standard/VLAN/Extend mode, PoE Budget, bandwidth control setup over LCD)
Layer 3 48-Port 10/100/1000T 802.3at PoE + 6-Port 10G SFP+ Managed Ethernet Switch (600W PoE budget, hardware-based Layer 3 RIPv1/v2, OSPFv2 dynamic routing, supports ERPS Ring, PoE PD alive check and schedule management)
Layer 3 48-Port 10/100/1000T 802.3at PoE + 6-Port 10G SFP+ Managed Ethernet Switch (600W PoE budget, hardware-based Layer 3 RIPv1/v2, OSPFv2 dynamic routing, supports ERPS Ring, PoE PD alive check and schedule management)
от 24288 грн
L3 4-Port 10/100/1000T 802.3at PoE + 4-Port 2.5G 802.3bt PoE + 2-Port 10G SFP+ Managed Switch (240W PoE Budget, 200m Extend mode, ERPS Ring, ONVIF, CloudViewer app, MQTT, Cybersecurity features, Hardware Layer 3 RIPv1/v2, OSPFv2/v3 dynamic routing, supports1G, 2.5G SFP and 10G SFP+)
L3 4-Port 10/100/1000T 802.3at PoE + 4-Port 2.5G 802.3bt PoE + 2-Port 10G SFP+ Managed Switch (240W PoE Budget, 200m Extend mode, ERPS Ring, ONVIF, CloudViewer app, MQTT, Cybersecurity features, Hardware Layer 3 RIPv1/v2, OSPFv2/v3 dynamic routing, supports1G, 2.5G SFP and 10G SFP+)
4-Port 10/100/1000T 802.3at POE + 2-Port 10/100/1000T Desktop Switch (65W POE Budget, External Power Supply, Standard/VLAN/Extend mode)
4-Port 10/100/1000T 802.3at POE + 2-Port 10/100/1000T Desktop Switch (65W POE Budget, External Power Supply, Standard/VLAN/Extend mode)
