Промислові комутатори, маршрутизатори
Акція
IP30 Industrial L2/L4 4-Port 10/100/1000T + 2-Port 100/1000X SFP Managed Switch (-40~75 degrees C, dual redundant power input on 9~48VDC/24VAC terminal block, supports ERPS Ring, CloudViewer app, MQTT and Cybersecurity feature)
Акція
IGS-4215-4T2S - Industrial L2/L4 4-Port 10/100/1000T...
IP30 Industrial L2/L4 4-Port 10/100/1000T + 2-Port 100/1000X SFP Managed Switch (-40~75 degrees C, dual redundant power input on 9~48VDC/24VAC terminal block, supports ERPS Ring, CloudViewer app, MQTT and Cybersecurity feature)
Planet
від 11 558,00 грн
Акція
.jpg "IGS-600-4PH24 Неуправляемый гигабитный Ethernet коммутатор на 6 портов, 4xPoE,(120W)")
6x GbE RJ45 з 4x PoE 120W, 24/48VDC Некерований гігабітний комутатор
Акція
IGS-600-4PH24 Неуправляемый гигабитный Ethernet комму...
6x GbE RJ45 з 4x PoE 120W, 24/48VDC Некерований гігабітний комутатор
CTC Union
від 22 575,00 грн
Акція
IXR-GS24044X - Промисловий 10G комутатор L3
від 314029 грн
від 314029 грн
Комутатор L3 на 24 порти FE/GbE SFP + 4 порти GbE RJ45 + 4 порти 1G/2.5G/10G SFP+ у стійку
Акція
IXR-GS24044X - Промышленный 10G коммутатор L3
Комутатор L3 на 24 порти FE/GbE SFP + 4 порти GbE RJ45 + 4 порти 1G/2.5G/10G SFP+ у стійку
CTC Union
від 314 029,00 грн
Акція
| Hardware Specifications | |
|---|---|
| Copper Ports | 8 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports (Ports 1 to 8) |
| SFP Ports | 4 10GBASE-SR/LR SFP+ interfaces (Port XG1 to Port XG4) Backward compatible with 1G/2.5GBASE-SX/LX/BX SFP transceivers |
| Console | 1 x USB Type C to RS232 serial port (115200,8, N, 1) |
| Reset Button | < 5 sec: System reboot > 5 sec: Factory default |
| Connector | Removable 6-pin terminal block Pin 1/2 for Power 1; Pin 3/4 for fault alarm; Pin 5/6 for Power 2 Removable 6-pin terminal block for DI/DO interface Pin 1/2 for DI 1 & 2, Pin 3/4 for DO 1 & 2, Pin 5/6 for GND |
| Alarm | One relay output for power failure. Alarm relay current carry ability: 1A @ 24V AC |
| DI, DO | 2 digital input (DI) Level 0: -24V~2.1V (±0.1V) Level 1: 2.1V~24V (±0.1V) Input load to 24V DC, 10mA max. 2 digital output (DO) Open collector to 24V DC, 100mA max. |
| Power Requirements | 9~48V DC, 2A (max.) or 24V AC, 0.8A (max.) |
| Power Consumption / Dissipation | DC：Max. 5.57 watts / 19BTU (system on) Max. 11.6 watts / 39.6BTU (Full loading) AC：Max. 4.7 watts / 16.04BTU (system on) Max. 10.6 watts / 36.2BTU (Full loading) |
| Dimensions (W x D x H) | 76 x 135 x 152 mm |
| Weight | 1232g |
| Enclosure | IP30 aluminum case |
| Installation | DIN-rail kit and wall-mount ear |
| ESD Protection | Contact Discharge 6KV DC Air Discharge 8KV DC |
| LED | System: Power 1 (Green) Power 2 (Green) Alarm (Red) Ring (Green) R.O.(Green) I/O (Red) Per 10/100/1000T RJ45: Up：1000 LNK/ACT (Green) Down：10/100 LNK/ACT (Amber) Per 10G SFP Interface: 1G/2.5G LNK/ACT (Green) 100/10G LNK/ACT (Amber) |
| Switching Specifications | |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 96Gbps/non-blocking |
| Switch Throughput@64 bytes | 71.43Mpps @64 bytes |
| MAC Address Table | 16K entries |
| Shared Data Buffer | 12Mbits |
| Flow Control | IEEE 802.3x pause frame for full duplex Back pressure for half duplex |
| Jumbo Frame | 12 Kbytes |
| Layer 2 Functions | |
| Port Mirroring | TX/RX/Both Many-to-1 monitor Up to 4 sessions |
| VLAN | 802.1Q tagged VLAN 802.1ad Q-in-Q tunneling (VLAN stacking) Voice VLAN Protocol VLAN Private VLAN (Protected port) GVRP Management VLAN Up to 256 VLAN groups, out of 4094 VLAN IDs |
| Link Aggregation | IEEE 802.3ad LACP and static trunk Supports 8 groups with 8 ports per trunk |
| Spanning Tree Protocol | IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) STP BPDU Guard, BPDU Filtering and BPDU Forwarding |
| IGMP Snooping | IPv4 IGMP snooping v2, v3 IGMP querier Up to 256 multicast groups |
| MLD Snooping | IPv6 MLD snooping v2, v3, up to 256 multicast groups |
| Access Control List | IPv4/IPv6 IP-based ACL/MAC-based ACL IPv4/IPv6 IP-based ACE/MAC-based ACE |
| QoS | 8 mapping IDs to 8 level priority queues Port number 802.1p priority DSCP/IP precedence of IPv4/IPv6 packets Traffic classification based, strict priority and WRR Ingress/Egress Rate Limit per port bandwidth control |
| Ring | Supports ERPS, and complies with ITU-T G.8032 Recovery time < 450ms |
| Security Functions | |
| Access Control List | IPv4/IPv6 IP-based ACL/MAC-based ACL IPv4/IPv6 IP-based ACE/MAC-based ACE Max. 256 ACL entries |
| Port Security | Built-in RADIUS client to co-operate with RADIUS server RADIUS/TACACS+ user access authentication |
| MAC Security | IP-MAC port binding MAC filter Static MAC address, max. 256 static MAC entries |
| Enhanced Security | HCP Snooping and DHCP Option82 STP BPDU guard, BPDU filtering and BPDU forwarding DoS attack prevention ARP inspection IP source guard |
| Management Functions | |
| Basic Management Interfaces | USB to RS232 Console Web browser Telnet SNMP v1, v2c |
| Secure Management Interfaces | SSHv2, TLSv1.2, SNMP v3 |
| System Management | Firmware upgrade by HTTP/TFTP protocol through Ethernet network Configuration upload/download through HTTP/TFTP LLDP protocol SNTP PLANET Smart Discovery Utility PLANET NMS System/CloudViewer/CloudViewerPro |
| Event Management | Remote/Local Syslog System log |
| SNMP MIBs | RFC 1213 MIB-II RFC 1215 Generic Traps RFC 1493 Bridge MIB RFC 2674 Bridge MIB Extensions RFC 2737 Entity MIB (Version 2) RFC 2819 RMON (1, 2, 3, 9) RFC 2863 Interface Group MIB RFC 3635 Ethernet-like MIB |
| Standards Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Stability Testing | IEC 60068-2-32 (free fall) IEC 60068-2-27 (shock) IEC 60068-2-6 (vibration) |
| Standards Compliance | IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX/100BASE-FX IEEE 802.3z Gigabit SX/LX IEEE 802.3ab Gigabit 1000BASE-T IEEE802.3ae 10Gb/s Ethernet IEEE 802.3x Flow Control and Back Pressure IEEE 802.3ad Port Trunk with LACP IEEE 802.1D Spanning Tree Protocol IEEE 802.1w Rapid Spanning Tree Protocol IEEE 802.1s Multiple Spanning Tree Protocol IEEE 802.1p Class of Service IEEE 802.1Q VLAN Tagging IEEE 802.1ab LLDP IEEE 802.3az for Energy-Efficient Ethernet RFC 768 UDP RFC 783 TFTP RFC 791 IP RFC 792 ICMP RFC 2068 HTTP RFC 1112 IGMP v1 RFC 2236 IGMP v2 RFC 3376 IGMP v3 RFC 2710 MLD v1 RFC 3810 MLD v2 ITU-T G.8032 ERPS Ring |
| Environment | |
| Operating Temperature | -40 ~ 75 °C |
| Storage Temperature | -40 ~ 85 °C |
| Humidity | 5 ~ 95% (non-condensing) |
Акція
IGS-4215-8T4X - Industrial L2/L4 8-Port 10/100/1000T...
| Hardware Specifications | |
|---|---|
| Copper Ports | 8 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports (Ports 1 to 8) |
| SFP Ports | 4 10GBASE-SR/LR SFP+ interfaces (Port XG1 to Port XG4) Backward compatible with 1G/2.5GBASE-SX/LX/BX SFP transceivers |
| Console | 1 x USB Type C to RS232 serial port (115200,8, N, 1) |
| Reset Button | < 5 sec: System reboot > 5 sec: Factory default |
| Connector | Removable 6-pin terminal block Pin 1/2 for Power 1; Pin 3/4 for fault alarm; Pin 5/6 for Power 2 Removable 6-pin terminal block for DI/DO interface Pin 1/2 for DI 1 & 2, Pin 3/4 for DO 1 & 2, Pin 5/6 for GND |
| Alarm | One relay output for power failure. Alarm relay current carry ability: 1A @ 24V AC |
| DI, DO | 2 digital input (DI) Level 0: -24V~2.1V (±0.1V) Level 1: 2.1V~24V (±0.1V) Input load to 24V DC, 10mA max. 2 digital output (DO) Open collector to 24V DC, 100mA max. |
| Power Requirements | 9~48V DC, 2A (max.) or 24V AC, 0.8A (max.) |
| Power Consumption / Dissipation | DC：Max. 5.57 watts / 19BTU (system on) Max. 11.6 watts / 39.6BTU (Full loading) AC：Max. 4.7 watts / 16.04BTU (system on) Max. 10.6 watts / 36.2BTU (Full loading) |
| Dimensions (W x D x H) | 76 x 135 x 152 mm |
| Weight | 1232g |
| Enclosure | IP30 aluminum case |
| Installation | DIN-rail kit and wall-mount ear |
| ESD Protection | Contact Discharge 6KV DC Air Discharge 8KV DC |
| LED | System: Power 1 (Green) Power 2 (Green) Alarm (Red) Ring (Green) R.O.(Green) I/O (Red) Per 10/100/1000T RJ45: Up：1000 LNK/ACT (Green) Down：10/100 LNK/ACT (Amber) Per 10G SFP Interface: 1G/2.5G LNK/ACT (Green) 100/10G LNK/ACT (Amber) |
| Switching Specifications | |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 96Gbps/non-blocking |
| Switch Throughput@64 bytes | 71.43Mpps @64 bytes |
| MAC Address Table | 16K entries |
| Shared Data Buffer | 12Mbits |
| Flow Control | IEEE 802.3x pause frame for full duplex Back pressure for half duplex |
| Jumbo Frame | 12 Kbytes |
| Layer 2 Functions | |
| Port Mirroring | TX/RX/Both Many-to-1 monitor Up to 4 sessions |
| VLAN | 802.1Q tagged VLAN 802.1ad Q-in-Q tunneling (VLAN stacking) Voice VLAN Protocol VLAN Private VLAN (Protected port) GVRP Management VLAN Up to 256 VLAN groups, out of 4094 VLAN IDs |
| Link Aggregation | IEEE 802.3ad LACP and static trunk Supports 8 groups with 8 ports per trunk |
| Spanning Tree Protocol | IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) STP BPDU Guard, BPDU Filtering and BPDU Forwarding |
| IGMP Snooping | IPv4 IGMP snooping v2, v3 IGMP querier Up to 256 multicast groups |
| MLD Snooping | IPv6 MLD snooping v2, v3, up to 256 multicast groups |
| Access Control List | IPv4/IPv6 IP-based ACL/MAC-based ACL IPv4/IPv6 IP-based ACE/MAC-based ACE |
| QoS | 8 mapping IDs to 8 level priority queues Port number 802.1p priority DSCP/IP precedence of IPv4/IPv6 packets Traffic classification based, strict priority and WRR Ingress/Egress Rate Limit per port bandwidth control |
| Ring | Supports ERPS, and complies with ITU-T G.8032 Recovery time < 450ms |
| Security Functions | |
| Access Control List | IPv4/IPv6 IP-based ACL/MAC-based ACL IPv4/IPv6 IP-based ACE/MAC-based ACE Max. 256 ACL entries |
| Port Security | Built-in RADIUS client to co-operate with RADIUS server RADIUS/TACACS+ user access authentication |
| MAC Security | IP-MAC port binding MAC filter Static MAC address, max. 256 static MAC entries |
| Enhanced Security | HCP Snooping and DHCP Option82 STP BPDU guard, BPDU filtering and BPDU forwarding DoS attack prevention ARP inspection IP source guard |
| Management Functions | |
| Basic Management Interfaces | USB to RS232 Console Web browser Telnet SNMP v1, v2c |
| Secure Management Interfaces | SSHv2, TLSv1.2, SNMP v3 |
| System Management | Firmware upgrade by HTTP/TFTP protocol through Ethernet network Configuration upload/download through HTTP/TFTP LLDP protocol SNTP PLANET Smart Discovery Utility PLANET NMS System/CloudViewer/CloudViewerPro |
| Event Management | Remote/Local Syslog System log |
| SNMP MIBs | RFC 1213 MIB-II RFC 1215 Generic Traps RFC 1493 Bridge MIB RFC 2674 Bridge MIB Extensions RFC 2737 Entity MIB (Version 2) RFC 2819 RMON (1, 2, 3, 9) RFC 2863 Interface Group MIB RFC 3635 Ethernet-like MIB |
| Standards Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Stability Testing | IEC 60068-2-32 (free fall) IEC 60068-2-27 (shock) IEC 60068-2-6 (vibration) |
| Standards Compliance | IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX/100BASE-FX IEEE 802.3z Gigabit SX/LX IEEE 802.3ab Gigabit 1000BASE-T IEEE802.3ae 10Gb/s Ethernet IEEE 802.3x Flow Control and Back Pressure IEEE 802.3ad Port Trunk with LACP IEEE 802.1D Spanning Tree Protocol IEEE 802.1w Rapid Spanning Tree Protocol IEEE 802.1s Multiple Spanning Tree Protocol IEEE 802.1p Class of Service IEEE 802.1Q VLAN Tagging IEEE 802.1ab LLDP IEEE 802.3az for Energy-Efficient Ethernet RFC 768 UDP RFC 783 TFTP RFC 791 IP RFC 792 ICMP RFC 2068 HTTP RFC 1112 IGMP v1 RFC 2236 IGMP v2 RFC 3376 IGMP v3 RFC 2710 MLD v1 RFC 3810 MLD v2 ITU-T G.8032 ERPS Ring |
| Environment | |
| Operating Temperature | -40 ~ 75 °C |
| Storage Temperature | -40 ~ 85 °C |
| Humidity | 5 ~ 95% (non-condensing) |
Planet
від 25 103,00 грн
Акція
IP30 Industrial L3 4-Port 2.5GBASE-T + 2-Port 10GBASE-X SFP+ Managed Ethernet Switch (-40 to 75 C, dual redundant power input on 9~48VDC terminal block, DIDO, ERPS Ring, 1588 PTP TC, Modbus TCP, Cybersecurity features, Layer 3 RIPv1/v2, OSPFv2/v3 dynamic routing, supports MQTT, supports 1000X, 2.5G SFP and 10G SFP+)
Акція
IGS-6325-4T2X - Industrial Layer 3 4-Port 2.5GBASE-T...
IP30 Industrial L3 4-Port 2.5GBASE-T + 2-Port 10GBASE-X SFP+ Managed Ethernet Switch (-40 to 75 C, dual redundant power input on 9~48VDC terminal block, DIDO, ERPS Ring, 1588 PTP TC, Modbus TCP, Cybersecurity features, Layer 3 RIPv1/v2, OSPFv2/v3 dynamic routing, supports MQTT, supports 1000X, 2.5G SFP and 10G SFP+)
Planet
від 23 388,00 грн
Акція
.webp "Неуправляемый коммутатор IFS-402F 4x 10/100Base-TX + 2 оптических порта Fast Ethernet")
4x GbE RJ45 + 2x 100Base Fiber (ST/SC) Промисловий комутатор
Акція
Неуправляемый коммутатор IFS-402F 4x 10/100Base-TX +...
4x GbE RJ45 + 2x 100Base Fiber (ST/SC) Промисловий комутатор
CTC Union
від 14 018,00 грн
Акція
Акція
Edgecore
від 0,00 грн
Акція
.webp "Неуправляемый коммутатор IFS-802GS 8x 10/100Base–TX + 2 SFP Gigabit Ethernet")
8x 10/100Base RJ45 + 2x 1000Base SFP Fast Ethernet комутатор
Акція
Неуправляемый коммутатор IFS-802GS 8x 10/100Base–TX +...
8x 10/100Base RJ45 + 2x 1000Base SFP Fast Ethernet комутатор
CTC Union
від 10 148,00 грн
Акція
.webp "IFS-1602GS - Неуправляемый коммутатор (16x 10/100Base–TX + 2 SFP Gigabit Ethernet)")
16x 10/100Base RJ45 + 2x 1000Base SFP комутатор Fast Ethernet
Акція
IFS-1602GS - Неуправляемый коммутатор (16x 10/100Base...
16x 10/100Base RJ45 + 2x 1000Base SFP комутатор Fast Ethernet
CTC Union
від 18 361,00 грн
